• 100amp 3 Phase 4 wire
• Direct Connected
• 5 Years Guarantee
• LCD or Mechanical Display
• Pulse Output
• Class 1
Voltage: 230/400V AC
Frequency: 50Hz / 60Hz (+/- 10%)
Current: 100A or -/5A
Power consumption: < 2W / 10VA per phase
AC Voltage withstand: 2KV – 1 minute
Impulse voltage withstand: 6KV – 1,2μS waveform
Output: SO according to DIN43864
Temperature range: 20°C ~ +55°C
Case: 126 mm DIN Rail mounted
Dimensions: 126x100x65 mm (w x h x d)
Accuracy class: 1
Brand | General |
---|
